Home » Box Dumper - 6000 lbs - 51"x48" Chute - Ultra-Heavy Duty - Valley Craft
Valley Craft

Box Dumper - 6000 lbs - 51"x48" Chute - Ultra-Heavy Duty - Valley Craft

SKU: F89022
$9,627.06
Dump Height
Power
Estimated Lead Time:4 to 5 Weeks

Valley Craft’s Box Dumpers are the perfect solution to effortlessly dump material with improved efficiency while reducing employee fatigue or injury. These premium box dumpers are designed to be compatible with a variety of gaylords, crates, tubs, cartons and other containers to fit your needs.

Made in the USA
  • 6,000 lb. load capacity.
  • Effortlessly dump material with improved efficiency and reduced fatigue or injury.
  • Ideal for use with a variety of gaylords, totes, crates, tubs, cartons, and other containers.
  • Reduce need for manual lifting, bending, and loading.
  • Chute size accommodates containers up to 51”W x 48”D.
  • Simply load containers by hand or using a standard pallet jack.
  • Spring-loaded hold down bar compatible with containers 30” to 56″ in height, adjustable on 2” increments.
  • Operate using convenient handheld pendant with magnetic back, controlling the 3 phase 60 hertz, 230 or 460 volt motor (2HP).
  • 30 second powered dump cycle, with gravity return.
  • Smooth operation utilizing single flow hydraulic control valve system.
  • Safely stop and start at any point during dump cycle.
  • Heavy duty 7 gauge steel construction.
  • Predrilled mounting holes provide ability to bolt unit to the floor for added stability.
  • Simply load containers at floor level.
  • Premium powder coat paint finish.
  • Ships fully assembled.

Dimensions Sheet - 36" Dump Height (pdf)

Dimensions Sheet - 48" Dump Height (pdf)

Dimensions Sheet - 60" Dump Height (pdf)

Dimensions Sheet - 72" Dump Height (pdf)
